Bitumen is a hydrocarbon material with high viscosity and colloidal structure, and black to dark brown color and is completely dissolvable in Carbon Disulfide and Carbon Tetrachloride. Being impenetrable to moisture and water, electrical insulation, elasticity, moderate resistance against acids, bases and salts and adhesion to other materials are the most important features of bitumen.
The most production type of bitumen in the world is petroleum bitumen which is obtained from crude oil distillation and they are classified based on Penetration Grade (standard ASTM-D5).
| BITUMEN TYPE | GRADES | PACKING |
|---|---|---|
| Bitumen | 60/70 | Barrel |
| Bitumen | 85/100 | Bulk |
| Bitumen | 40/50 |
Bitumen Grade: 10/20
| Analysis Parameter | Value | Unit | Test Method |
|---|---|---|---|
| Density at 25°C | 1010-1060 | Kg/m3 | ASTM D7 or D 3289 |
| Penetration at 25°C | 10-20 | Mm/10 | ASTM D5 |
| Softening Point | 120 | °C | ASTM D36 |
| Ductility at 25°C | 3 Min | cm | ASTM D113 |
| Loss on heating | 0.2 Max | Wt % | ASTM D6 |
| Drop in Penetration after heating | 20 Max | % | ASTM D5 and D6 |
| Flash Point | 225 Min | °C | ASTM D92 |
| Solubility in Trichloroethylene | 99.5 Min | Wt % | ASTM D4 |
| Spot test | Negative | – | AASHTO T 102 |
10/20 bitumen is a bitumen that is obtained
through aeration on a vacuum baton (the raw
material of bitumen production that is taken
from the bottom of the distillation tower in the
vacuum of oil refineries) in bitumen units and
the degree
20/30 bitumen is a bitumen that is obtained
through aeration on avacuum baton (the raw
material for bitumen production that is taken
from the bottom of the distillation tower in the
vacuum of oil refineries) in bitumen units and
the degree of permeability (determining the
amount of bitumen hardness) It is between 20
and 30. Bitumen 20/30 is used in all kinds of
asphalt coverings and construction due to its
good adhesion properties. In terms of place of
use, bitumen 20/30 is
Bitumen Grade: 20/30
| Analysis Parameter | Unit | Limit | Test Method |
|---|---|---|---|
| Density@ 25°C | Kg/m3 | 1010-1060 | ASTM D7 or D 3289 |
| Penetration@ 25°C | Mm/10 | 20-30 | ASTM D5 |
| Softening Point | °C | 80-90 | ASTM D36 |
| Ductility@ 25°C | cm | 3 Min | ASTM D113 |
| Loss on heating | Wt % | 0.2 Max | ASTM D6 |
| Drop in Penetration after heating | % | 20 Max | ASTM D5 and D6 |
| Flash Point | °C | 225 Min | ASTM D92 |
| Solubility in Trichloroethylene | Wt % | 99.0 Min | ASTM D4 |
| Spot test | — | Negative | AASHTO T 102 |
Bitumen Grade: 30/40
| Analysis Parameter | Unit | Limit | Test Method |
|---|---|---|---|
| Density@ 25°C | Kg/m3 | 1010-1060 | ASTM D7 or D 3289 |
| Penetration@ 25°C | Mm/10 | 30-40 | ASTM D5 |
| Softening Point | °C | 55-63 | ASTM D36 |
| Ductility@ 25°C | cm | 100 Min | ASTM D113 |
| Loss on heating | Wt % | 0.2 Max | ASTM D6 |
| Drop in Penetration after heating | % | 20 Max | ASTM D5 and D6 |
| Flash Point | °C | 225 Min | ASTM D92 |
| Solubility in Trichloroethylene | Wt % | 99.0 Min | ASTM D2042 |
| Spot test | — | Negative | AASHTO T 102 |
Bitumen 30/40 is so-called a grade of refinery
bitumen obtained from the vacuum aeration of
a distillation tower and its permeability is
between 30 and 40. The most common use of
this type of bitumen is in road construction,
insulation, building construction and liquid
bitumen production.
In terms of place of use, bitumen 30/40 is more
suitable for very dry and tropical climates. In the
field of bitumen export, Seven To Seven,
including 30/40 bitumen, has produced 30/40
bitumen, prepared 30/40 bitumen, packaged
30/40 bitumen, made 30/40 bitumen
containers, and exported 30/40 bitumen.
Among the bitumen products of Seven To
Seven is the production of bitumen with a
permeability of 40/50. This product is also
purchased from two big poles of bitumen
industry (Naftji). 40/50 bitumen is a bitumen
obtained by aeration process on vacuum baton
(primary material of bitumen production which
is taken from the bottom of the distillation
tower in the vacuum of oil refineries) in
bitumen production units in such a way that its
permeability is between 40 to be 50 Use in road
construction industries for tropical areas,
insulation and production of liquid bitumen is
one of the applications of this type of bitumen.
Bitumen Grade: 40/50
| Analysis Parameter | Unit | Limit | Test Method |
|---|---|---|---|
| Density@ 25°C | Kg/m3 | 1010-1060 | ASTM D7 or D 3289 |
| Penetration@ 25°C | Mm/10 | 40-50 | ASTM D5 |
| Softening Point | °C | 52-60 | ASTM D36 |
| Ductility@ 25°C | cm | 100Min | ASTM D113 |
| Loss on heating | Wt % | 0.2 Max | ASTM D6 |
| Drop in Penetration after heating | % | 20 Max | ASTM D5 |
| Flash Point | °C | 232 Min | ASTM D92 |
| Solubility in Trichloroethylene | Wt % | 99.0 Min | ASTM D2042 |
| Spot test | — | Negative | AASHTO T 102 |
| Viscosity @60°C | P | 4000±800 | ASTM D2171 |
| Viscosity @ 135°C | cSt | 400 min | ASTM D2170 |
Bitumen Grade: 60/70
| Analysis Parameter | Unit | Limit | Test Method |
|---|---|---|---|
| Density@ 25°C | Kg/m3 | 1010-1060 | ASTM D7 or D 3289 |
| Penetration@ 25°C | Mm/10 | 60-70 | ASTM D5 |
| Softening Point | °C | 46 | ASTM D36 |
| Ductility@ 25°C | cm | 100Min | ASTM D113 |
| Loss on heating | Wt % | 0.2 Max | ASTM D6 |
| Drop in Penetration after heating | % | 20 Max | ASTM D5 |
| Flash Point | °C | 232 Min | ASTM D92 |
| Solubility in Trichloroethylene | Wt % | 99.0 Min | ASTM D2042 |
| Spot test | — | Negative | AASHTO T 102 |
| Viscosity @60°C | P | 2000±300 | ASTM D2171 |
| Viscosity @ 135°C | cSt | 300 min | ASTM D2170 |
Bitumen 60/70 is one of the types of bitumen
produced by Seven To Seven. Bitumen 60/70 is
so-called a grade of refinery bitumen obtained
from the vacuum aeration of a distillation tower
and its penetration degree is between 60 and
70. The most common use of this type of
bitumen is in road construction, insulation,
building construction and liquid bitumen
production. In terms of place of use, bitumen
60/70 is more suitable for temperate climates.
In this regard, Seven To Seven is one of the
companies producing high-quality bitumen
60/70 and making its containers in Iran.
Bitumen 60/70 is part of the export bitumen of
Seven To Seven and is exported in large
quantities to other countries. Seven To Seven
has been able to take a big step in promoting
Iranian high-quality bitumen 60/70 by making
60/70 bitumen containers and exporting
high-quality 60/70 bitumen to other countries.
Bitumen grade 80/100 is a standard bitumen type of penetrating bitumen, which is usually known as road grade
bitumen and has excellent properties for road construction and construction of asphalt and road coating. This
type of bitumen is mainly used in making hot asphalt mixture. Permeability grade bitumen such as 80/100
bitumen are bitumen that are obtained through the aeration process on the bottom of the distillation tower,
which is known as vacuum baton, so that the degree of permeability is between 80 and 100. Penetration grade
bitumen have thermoplastic property, this property causes the bitumen viscosity to decrease at high
temperature and increase at low temperature, and 80/100 bitumen is the most widely used in road coating.
Bitumen oil group is one of the 80/100 bitumen producers, 80/100 bitumen suppliers and major exporters of
80/100 bitumen in Iran. Seven To Seven sends its export bitumen to global markets by packaging standard
export metal barrels and packaging in flexi format and packaging on pallets. Seven To Seven has the ability to
produce and supply different grades of bitumen, including 80/100 bitumen, for buyers as soon as possible with
the best quality and the most appropriate price. Seven To Seven has been able to occupy a good position in the
export of this type of bitumen by producing 80/100 bitumen, selling quality 80/100 bitumen, packing 80/100
bitumen and making 80/100 bitumen containers.
Bitumen Grade: 80/100
| Analysis Parameter | Unit | Limit | Test Method |
|---|---|---|---|
| Density@ 25°C | Kg/m3 | 1010-1060 | ASTM D7 or D 3289 |
| Penetration@ 25°C | Mm/10 | 80-100 | ASTM D5 |
| Softening Point | °C | 42 | ASTM D36 |
| Ductility@ 25°C | cm | 100Min | ASTM D113 |
| Loss on heating | Wt % | 0.5 Max | ASTM D6 |
| Drop in Penetration after heating | % | 20 Max | ASTM D5 |
| Flash Point | °C | 232 Min | ASTM D92 |
| Solubility in Trichloroethylene | Wt % | 99.0 Min | ASTM D2042 |
| Spot test | — | Negative | AASHTO T 102 |
| Viscosity @60°C | P | 1000±200 | ASTM D2171 |
| Viscosity @ 135°C | cSt | 250 min | ASTM D2170 |
Bitumen Grade: 85/100
| Analysis Parameter | Unit | Limit | Test Method |
|---|---|---|---|
| Density@ 25°C | Kg/m3 | 1010-1060 | ASTM D7 or D 3289 |
| Penetration@ 25°C | Mm/10 | 85-100 | ASTM D5 |
| Softening Point | °C | 42 | ASTM D36 |
| Ductility@ 25°C | cm | 100Min | ASTM D113 |
| Loss on heating | Wt % | 0.5 Max | ASTM D6 |
| Drop in Penetration after heating | % | 20 Max | ASTM D5 |
| Flash Point | °C | 232 Min | ASTM D92 |
| Solubility in Trichloroethylene | Wt % | 99.0 Min | ASTM D2042 |
| Spot test | — | Negative | AASHTO T 102 |
| Viscosity @60°C | P | 1000±200 | ASTM D2171 |
| Viscosity @ 135°C | cSt | 250 min | ASTM D2170 |
Which of the production products of Seven To Seven is bitumen with a penetration degree (bitumen hardness
value) of 85/100. Bitumen 85/100 is a bitumen that is obtained by aeration process on vacuum baton (primary
material of bitumen production which is taken from the bottom of the distillation tower in the vacuum of oil
refineries) in bitumen units. This bitumen is purchased in the form of a seal from Naftji Oil Refinery and is
unloaded at the Seven To Seven plant and is packaged in standard export barrels of 160 and 240 kg with the
highest quality and in accordance with international standards. The most used bitumen 85/100 is in the
industries of road construction, insulation work, construction and also the production of liquid bitumen. In
terms of the place of use, this product is more suitable for the cold regions of the country. Bitumen oil group
company has been able to take a big step in promoting high-quality Iranian 85/100 bitumen by producing
85/100 bitumen, packaging 85/100 bitumen, packing 85/100 bitumen and exporting 85/100 bitumen to more
than 40 countries.
